Introduction

Togai’s Alerting System is designed to monitor various entities for specific conditions and trigger incidents when these conditions are met. It is composed of alert templates, alerts, and incidents. The system allows users to create alerts to define conditions and thresholds on state of a single entity or group of entities. If an alert condition is satisfied, the system will create an incident.

Entities of Alerts module

Alert template

An Alert Template serves as a blueprint for creating alerts that monitor specific entities for certain conditions. The purpose of an alert template is to define the logic and thresholds for triggering alerts in various scenarios. Commonly, the template blueprint has the structure resembling this: Property of the [Entity or entities] belonging to the [Owner] breaches the [Condition] where condition in turn has a condition operation and threshold. Example:

Alert template: credit_low_balance Entity: Credits Owner: Account Parameters: Threshold Condition: Balance of Entity: Credits belonging to Owner: Account drops below Parameter: Threshold

Alert

An Alert can be imagined as an instance of an alert templates combined with a set of parameters. Alerts monitor data for breaches depending on the configured condition thresholds. Example:

Alert template: credit_low_balance Entity: Credits Owner: Account = Acc1 Parameters: Threshold = 100$ Condition: Balance of Entity: Credits belonging to Owner: Account Acc1 drops below Parameter: 100$

Incident

An Incident is created when the condition defined in an alert is met, i.e., when the threshold is breached. The incident serves as a notification or event that requires action. Each incident record includes the open and close time stamps, as well as snapshots of the data being evaluated around the time of each incident also termed as Report Data.

Short Summary:

Alert Template + Parameters => Alert
Alert + Condition is breached => Incident containing Report Data

Alert templates

alertTemplateId	Entity	Owner Details	Parameters	Report Data	Auto Resolvable
`unprocessed_events`	`N/A`	`N/A`	unprocessedEventParams	unprocessedEventReportData	`FALSE`
`usage_breach`	`USAGE_METER`	`ACCOUNT`	usageBreachParams	usageBreachReportData	`FALSE`
`credit_low_balance`	`CREDIT`	`ACCOUNT`	lowBalanceParams	lowBalanceReportData	`TRUE`
`wallet_low_balance`	`WALLET`	`ACCOUNT`	lowBalanceParams	lowBalanceReportData	`TRUE`
`entitlement_low_balance`	`FEATURE`	`ACCOUNT`	lowBalanceParams	lowBalanceReportData	`TRUE`
`invoice_due_breach`	`INVOICE`	`ACCOUNT`	invoiceDueBreachParams	invoiceDueBreachReportData	`FALSE`
`invoice_overdue_breach`	`INVOICE`	`ACCOUNT`	invoiceDueBreachParams	invoiceDueBreachReportData	`FALSE`
`unpaid_invoice_amount_breach`	`null`	`ACCOUNT`	unpaidInvoiceAmtBreachParams	unpaidInvoiceAmtBreachReportData	`TRUE`

Parameter Schema

UnprocessedEvent Params

Hide child attributes

window

integer

This is the last window number of minutes from alert interval time that will be considered for generating the alert

threshold

integer

required

Threshold limit above which incidents are created

schemaName

integer

Name of the event schema for which unprocessed events count is required

UsageBreach Params

Hide child attributes

threshold

integer

required

Threshold limit for a given aggregation period above which alerts are generated.

aggregation

enum

Allowed Values: DAY, WEEK, MONTH, PRICING_CYCLE. Defaults to PRICING_CYCLE

LowBalance Params

Hide child attributes

minThreshold

integer

required

Minimum threshold limit below which incidents are created

InvoiceDueBreach Params

Hide child attributes

thresholdDays

integer

required

Threshold limit for days above which incidents are created

thresholdSum

integer

Threshold limit for invoice sum above which incidents are created

UnpaidInvoiceAmountBreach Params

Hide child attributes

thresholdSum

integer

required

Threshold limit for unpaid invoice sum above which incidents are created

Report Data Schema

UnprocessedEvent Report Data

Hide child attributes

count

integer

required

Count of the unprocessed events

UsageBreach Report Data

Hide child attributes

usage

integer

required

Usage units

LowBalance Report Data

Hide child attributes

balance

integer

required

Remaining balance of credits for an account

totalGrantedUnits

integer

Total granted units of credits for an account

accountId

string

accountId corresponding to the alert

InvoiceDueBreach Report Data

Hide child attributes

count

integer

required

Sum of all invoices that are due / overdue after threshold number of days

sum

integer

Count of invoices that are due / overdue after threshold number of days”

accountId

string

accountId corresponding to the alert

UnpaidInvoiceAmountBreach Report Data

Hide child attributes

sum

number

required

Sum of the total unpaid amount

accountId

string

required

accountId corresponding to the alert

sumOfDueInvoices

number

required

Sum of the due invoices contributing to the outstanding sum

sumOfDraftInvoices

number

required

Sum of the draft invoices contributing to the outstanding sum

numberOfDueInvoices

integer

required

Number of due invoices contributing to the outstanding sum

numberOfDraftInvoices

integer

required

Number of draft invoices contributing to the outstanding sum

sumOfPartiallyPaidInvoices

number

required

Sum of the partially paid invoices contributing to the outstanding sum

numberOfPartiallyPaidInvoices

integer

required

Number of partially paid invoices contributing to the outstanding sum
